Systems and Channelisation


Channel
type
Operating
band
UplinkDownlink
ChannelCarrier frequencyChannelCarrier frequency
UARFCNXXXII-10 MHz66171454.4 MHz
EARFCNb29-10 MHz9660717 MHz
EARFCNb32-10 MHz99201452 MHz
EARFCNb67-10 MHz67336738 MHz
EARFCNb69-10 MHz678362570 MHz
EARFCNb75-10 MHz694661432 MHz
EARFCNb76-10 MHz703161427 MHz






 BandUplink (UE Tx, BS Rx)Downlink (BS Tx, UE Rx)Duplex GapMode
n1 1920 - 1980 MHz2110 - 2170 MHz190 MHzFDD
n2 1850 - 1910 MHz1930 - 1990 MHz 80 MHzFDD
n3 1710 - 1785 MHz1805 - 1880 MHz 95 MHzFDD
n5 824 - 849 MHz 869 - 894 MHz 45 MHzFDD
n7 2500 - 2570 MHz2620 - 2690 MHz120 MHzFDD
n8 880 - 915 MHz 925 - 960 MHz 45 MHzFDD
n12 699 - 716 MHz 729 - 746 MHz 30 MHzFDD
n14 788 - 798 MHz 758 - 768 MHz-30 MHzFDD
n18 815 - 830 MHz 860 - 875 MHz 45 MHzFDD
n20 832 - 862 MHz 791 - 821 MHz-41 MHzFDD
n25 1850 - 1915 MHz1930 - 1995 MHz 80 MHzFDD
n28 703 - 748 MHz 758 - 803 MHz 55 MHzFDD
n30 2305 - 2315 MHz2350 - 2360 MHz 45 MHzFDD
n34 2010 - 2025 MHzTDD
n38 2570 - 2620 MHzTDD
n39 1880 - 1920 MHzTDD
n40 2300 - 2400 MHzTDD
n41 2496 - 2690 MHzTDD
n46 5150 - 5925 MHzTDD
n48 3550 - 3700 MHzTDD
n50 1432 - 1517 MHzTDD
n51 1427 - 1432 MHzTDD
n53 2483.5 - 2495 MHzTDD
n65 1920 - 2010 MHz2110 - 2200 MHz190 MHzFDD
n66 1710 - 1780 MHz2110 - 2200 MHz400 MHzFDD
n70 1695 - 1710 MHz1995 - 2010 MHz300 MHzFDD
n71 663 - 698 MHz 617 - 652 MHz-46 MHzFDD
n74 1427 - 1470 MHz1475 - 1518 MHz 48 MHzFDD
n75 1432 - 1517 MHz SDL
n76 1427 - 1432 MHz SDL
n77 3300 - 4200 MHzTDD
n78 3300 - 3800 MHzTDD
n79 4400 - 5000 MHzTDD
n80 1710 - 1785 MHz SUL
n81 880 - 915 MHz SUL
n82 832 - 862 MHz SUL
n83 703 - 748 MHz SUL
n84 1920 - 1980 MHz SUL
n86 1710 - 1780 MHz SUL
n89 824 - 849 MHz SUL
n90 2496 - 2690 MHzTDD
n91 832 - 862 MHz1427 - 1432 MHz565-600 MHzFDD
n92 832 - 862 MHz1432 - 1517 MHz570-685 MHzFDD
n93 880 - 915 MHz1427 - 1432 MHz512-552 MHzFDD
n94 880 - 915 MHz1432 - 1517 MHz517-637 MHzFDD
n95 2010 - 2025 MHz SUL
n96 5925 - 7125 MHzTDD
n25726500 - 29500 MHzTDD
n25824250 - 27500 MHzTDD
n25939500 - 43500 MHzTDD
n26037000 - 40000 MHzTDD
n26127500 - 28350 MHzTDD
 BandChannelFrequency RangeCenterRegion
2.4 GHz 12401 - 2423 MHz2412 MHzEurope, US, Japan
2.4 GHz 22406 - 2428 MHz2417 MHzEurope, US, Japan
2.4 GHz 32411 - 2433 MHz2422 MHzEurope, US, Japan
2.4 GHz 42416 - 2438 MHz2427 MHzEurope, US, Japan
2.4 GHz 52421 - 2443 MHz2432 MHzEurope, US, Japan
2.4 GHz 62426 - 2448 MHz2437 MHzEurope, US, Japan
2.4 GHz 72431 - 2453 MHz2442 MHzEurope, US, Japan
2.4 GHz 82436 - 2458 MHz2447 MHzEurope, US, Japan
2.4 GHz 92441 - 2463 MHz2452 MHzEurope, US, Japan
2.4 GHz 102446 - 2468 MHz2457 MHzEurope, US, Japan
2.4 GHz 112451 - 2473 MHz2462 MHzEurope, US, Japan
2.4 GHz 122456 - 2478 MHz2467 MHzEurope, Japan
2.4 GHz 132461 - 2483 MHz2472 MHzEurope, Japan
2.4 GHz 142473 - 2495 MHz2484 MHzJapan
5 GHz 325150 – 5170 MHz5160 MHzEU, US, Japan
5 GHz 345150 – 5190 MHz5170 MHzEU, US, Japan
5 GHz 365170 – 5190 MHz5180 MHzEU, US, Japan
5 GHz 385170 – 5210 MHz5190 MHzEU, US, Japan
5 GHz 405190 – 5210 MHz5200 MHzEU, US, Japan
5 GHz 425170 – 5250 MHz5210 MHzEU, US, Japan
5 GHz 445210 – 5230 MHz5220 MHzEU, US, Japan
5 GHz 465210 – 5250 MHz5230 MHzEU, US, Japan
5 GHz 485230 – 5250 MHz5240 MHzEU, US, Japan
5 GHz 505170 – 5330 MHz5250 MHzEU, US, Japan
5 GHz 525250 – 5270 MHz5260 MHzEU, US, Japan
5 GHz 545250 – 5290 MHz5270 MHzEU, US, Japan
5 GHz 565270 – 5290 MHz5280 MHzEU, US, Japan
5 GHz 585250 – 5330 MHz5290 MHzEU, US, Japan
5 GHz 605290 – 5310 MHz5300 MHzEU, US, Japan
5 GHz 625290 – 5330 MHz5310 MHzEU, US, Japan
5 GHz 645310 – 5330 MHz5320 MHzEU, US, Japan
5 GHz 685330 – 5350 MHz5340 MHzEU, US, Japan
5 GHz 965470 – 5490 MHz5480 MHzEU, US, Japan
5 GHz 1005490 – 5510 MHz5500 MHzEU, US, Japan
5 GHz 1025490 – 5530 MHz5510 MHzEU, US, Japan
5 GHz 1045510 – 5530 MHz5520 MHzEU, US, Japan
5 GHz 1065490 – 5570 MHz5530 MHzEU, US, Japan
5 GHz 1085530 – 5550 MHz5540 MHzEU, US, Japan
5 GHz 1105530 – 5570 MHz5550 MHzEU, US, Japan
5 GHz 1125550 – 5570 MHz5560 MHzEU, US, Japan
5 GHz 1145490 – 5650 MHz5570 MHzEU, US, Japan
5 GHz 1165570 – 5590 MHz5580 MHzEU, US, Japan
5 GHz 1185570 – 5610 MHz5590 MHzEU, US, Japan
5 GHz 1205590 – 5610 MHz5600 MHzEU, US, Japan
5 GHz 1225570 – 5650 MHz5610 MHzEU, US, Japan
5 GHz 1245610 – 5630 MHz5620 MHzEU, US, Japan
5 GHz 1265610 – 5650 MHz5630 MHzEU, US, Japan
5 GHz 1285630 – 5650 MHz5640 MHzEU, US, Japan
5 GHz 1325650 – 5670 MHz5660 MHzEU, US, Japan
5 GHz 1345650 – 5690 MHz5670 MHzEU, US, Japan
5 GHz 1365670 – 5690 MHz5680 MHzEU, US, Japan
5 GHz 1385650 – 5730 MHz5690 MHzEU, US, Japan
5 GHz 1405690 – 5710 MHz5700 MHzEU, US, Japan
5 GHz 1425690 – 5730 MHz5710 MHzEU, US, Japan
5 GHz 1445710 – 5730 MHz5720 MHzEU, US, Japan
5 GHz 1495735 – 5755 MHz5745 MHzUS
5 GHz 1515735 – 5775 MHz5755 MHzUS
5 GHz 1535755 – 5775 MHz5765 MHzUS
5 GHz 1555735 – 5815 MHz5775 MHzUS
5 GHz 1575775 – 5795 MHz5785 MHzUS
5 GHz 1595775 – 5815 MHz5795 MHzUS
5 GHz 1615795 – 5815 MHz5805 MHzUS
 BandChannelFrequency RangeCenterVision (B,G,H)Sound (B,G,H)
VHF I 1 40 - 47 MHz 43.5MHz 41.25 MHz 46.75 MHz
VHF I 2 47 - 54 MHz 50.5MHz 48.25 MHz 53.75 MHz
VHF I 3 54 - 61 MHz 57.5MHz 55.25 MHz 60.75 MHz
VHF I 4 61 - 68 MHz 64.5MHz 62.25 MHz 67.75 MHz
VHF III 5174 - 181 MHz177.5MHz175.25 MHz180.75 MHz
VHF III 6181 - 188 MHz184.5MHz182.25 MHz187.75 MHz
VHF III 7188 - 195 MHz191.5MHz189.25 MHz194.75 MHz
VHF III 8195 - 202 MHz198.5MHz196.25 MHz201.75 MHz
VHF III 9202 - 209 MHz205.5MHz203.25 MHz208.75 MHz
VHF III10209 - 216 MHz212.5MHz210.25 MHz215.75 MHz
VHF III11216 - 223 MHz219.5MHz217.25 MHz222.75 MHz
VHF III12223 - 230 MHz226.5MHz224.25 MHz229.75 MHz
UHF IV 21470 - 478 MHz474 MHz471.25 MHz476.75 MHz
UHF IV 22478 - 486 MHz482 MHz479.25 MHz484.75 MHz
UHF IV 23486 - 494 MHz490 MHz487.25 MHz492.75 MHz
UHF IV 24494 - 502 MHz498 MHz495.25 MHz500.75 MHz
UHF IV 25502 - 510 MHz506 MHz503.25 MHz508.75 MHz
UHF IV 26510 - 518 MHz514 MHz511.25 MHz516.75 MHz
UHF IV 27518 - 526 MHz522 MHz519.25 MHz524.75 MHz
UHF IV 28526 - 534 MHz530 MHz527.25 MHz532.75 MHz
UHF IV 29534 - 542 MHz538 MHz535.25 MHz540.75 MHz
UHF IV 30542 - 550 MHz546 MHz543.25 MHz548.75 MHz
UHF IV 31550 - 558 MHz554 MHz551.25 MHz556.75 MHz
UHF IV 32558 - 566 MHz562 MHz559.25 MHz564.75 MHz
UHF IV 33566 - 574 MHz570 MHz567.25 MHz572.75 MHz
UHF IV 34574 - 582 MHz578 MHz575.25 MHz580.75 MHz
UHF V 35582 - 590 MHz586 MHz583.25 MHz588.75 MHz
UHF V 36590 - 598 MHz594 MHz591.25 MHz596.75 MHz
UHF V 37598 - 606 MHz602 MHz599.25 MHz604.75 MHz
UHF V 38606 - 614 MHz610 MHz607.25 MHz612.75 MHz
UHF V 39614 - 622 MHz618 MHz615.25 MHz620.75 MHz
UHF V 40622 - 630 MHz626 MHz623.25 MHz628.75 MHz
UHF V 41630 - 638 MHz634 MHz631.25 MHz636.75 MHz
UHF V 42638 - 646 MHz642 MHz639.25 MHz644.75 MHz
UHF V 43646 - 654 MHz650 MHz647.25 MHz652.75 MHz
UHF V 44654 - 662 MHz658 MHz655.25 MHz660.75 MHz
UHF V 45662 - 670 MHz666 MHz663.25 MHz668.75 MHz
UHF V 46670 - 678 MHz674 MHz671.25 MHz676.75 MHz
UHF V 47678 - 686 MHz682 MHz679.25 MHz684.75 MHz
UHF V 48686 - 694 MHz690 MHz687.25 MHz692.75 MHz
UHF V 49694 - 702 MHz698 MHz695.25 MHz700.75 MHz
UHF V 50702 - 710 MHz706 MHz703.25 MHz708.75 MHz
UHF V 51710 - 718 MHz714 MHz711.25 MHz716.75 MHz
UHF V 52718 - 726 MHz722 MHz719.25 MHz724.75 MHz
UHF V 53726 - 734 MHz730 MHz727.25 MHz732.75 MHz
UHF V 54734 - 742 MHz738 MHz735.25 MHz740.75 MHz
UHF V 55742 - 750 MHz746 MHz743.25 MHz748.75 MHz
UHF V 56750 - 758 MHz754 MHz751.25 MHz756.75 MHz
UHF V 57758 - 766 MHz762 MHz759.25 MHz764.75 MHz
UHF V 58766 - 774 MHz770 MHz767.25 MHz772.75 MHz
UHF V 59774 - 782 MHz778 MHz775.25 MHz780.75 MHz
UHF V 60782 - 790 MHz786 MHz783.25 MHz788.75 MHz
UHF V 61790 - 798 MHz794 MHz791.25 MHz796.75 MHz
UHF V 62798 - 806 MHz802 MHz799.25 MHz804.75 MHz
UHF V 63806 - 814 MHz810 MHz807.25 MHz812.75 MHz
UHF V 64814 - 822 MHz818 MHz815.25 MHz820.75 MHz
UHF V 65822 - 830 MHz826 MHz823.25 MHz828.75 MHz
UHF V 66830 - 838 MHz834 MHz831.25 MHz836.75 MHz
UHF V 67838 - 846 MHz842 MHz839.25 MHz844.75 MHz
UHF V 68846 - 854 MHz850 MHz847.25 MHz852.75 MHz
UHF V 69854 - 862 MHz858 MHz855.25 MHz860.75 MHz
 BandChannelFrequency RangeCenter
III 5A 174.160 - 175.696 MHz 174.928 MHz
III 5B 175.872 - 177.408 MHz 176.640 MHz
III 5C 177.584 - 179.120 MHz 178.352 MHz
III 5D 179.296 - 180.832 MHz 180.064 MHz
III 6A 181.168 - 182.704 MHz 181.936 MHz
III 6B 182.880 - 184.416 MHz 183.648 MHz
III 6C 184.592 - 186.128 MHz 185.360 MHz
III 6D 186.304 - 187.840 MHz 187.072 MHz
III 7A 188.160 - 189.696 MHz 188.928 MHz
III 7B 189.872 - 191.408 MHz 190.640 MHz
III 7C 191.584 - 193.120 MHz 192.352 MHz
III 7D 193.296 - 194.832 MHz 194.064 MHz
III 8A 195.168 - 196.704 MHz 195.936 MHz
III 8B 196.880 - 198.416 MHz 197.648 MHz
III 8C 198.592 - 200.128 MHz 199.360 MHz
III 8D 200.304 - 201.840 MHz 201.072 MHz
III 9A 202.160 - 203.696 MHz 202.928 MHz
III 9B 203.872 - 205.408 MHz 204.640 MHz
III 9C 205.584 - 207.120 MHz 206.352 MHz
III 9D 207.296 - 208.832 MHz 208.064 MHz
III10A 209.168 - 210.704 MHz 209.936 MHz
III10B 210.880 - 212.416 MHz 211.648 MHz
III10C 212.592 - 214.128 MHz 213.360 MHz
III10D 214.304 - 215.840 MHz 215.072 MHz
III11A 216.160 - 217.696 MHz 216.928 MHz
III11B 217.872 - 219.408 MHz 218.640 MHz
III11C 219.584 - 221.120 MHz 220.352 MHz
III11D 221.296 - 222.832 MHz 222.064 MHz
III12A 223.168 - 224.704 MHz 223.936 MHz
III12B 224.880 - 226.416 MHz 225.648 MHz
III12C 226.592 - 228.128 MHz 227.360 MHz
III12D 228.304 - 229.840 MHz 229.072 MHz
III13A 230.016 - 231.552 MHz 230.784 MHz
III13B 231.728 - 233.264 MHz 232.496 MHz
III13C 233.440 - 234.976 MHz 234.208 MHz
III13D 235.008 - 236.544 MHz 235.776 MHz
III13E 236.720 - 238.256 MHz 237.488 MHz
III13F 238.432 - 239.968 MHz 239.200 MHz
L LA1452.192 - 1453.728 MHz1452.960 MHz
L LB1453.904 - 1455.440 MHz1454.672 MHz
L LC1455.616 - 1457.152 MHz1456.384 MHz
L LD1457.328 - 1458.864 MHz1458.096 MHz
L LE1459.040 - 1460.576 MHz1459.808 MHz
L LF1460.752 - 1462.288 MHz1461.520 MHz
L LG1462.464 - 1464.000 MHz1463.232 MHz
L LH1464.176 - 1465.712 MHz1464.944 MHz
L LI1465.888 - 1467.424 MHz1466.656 MHz
L LJ1467.600 - 1469.136 MHz1468.368 MHz
L LK1469.312 - 1470.848 MHz1470.080 MHz
L LL1471.024 - 1472.560 MHz1471.792 MHz
L LM1472.736 - 1474.272 MHz1473.504 MHz
L LN1474.448 - 1475.984 MHz1475.216 MHz
L LO1476.160 - 1477.696 MHz1476.928 MHz
L LP1477.872 - 1479.408 MHz1478.640 MHz
 BandChannelFrequency RangeCenter
II 1 87.2 - 87.4 MHz 87.3 MHz
II 2 87.5 - 87.7 MHz 87.6 MHz
II 3 87.8 - 88.0 MHz 87.9 MHz
II 4 88.1 - 88.3 MHz 88.2 MHz
II 5 88.4 - 88.6 MHz 88.5 MHz
II 6 88.7 - 88.9 MHz 88.8 MHz
II 7 89.0 - 89.2 MHz 89.1 MHz
II 8 89.3 - 89.5 MHz 89.4 MHz
II 9 89.6 - 89.8 MHz 89.7 MHz
II10 89.9 - 90.1 MHz 90.0 MHz
II11 90.2 - 90.4 MHz 90.3 MHz
II12 90.5 - 90.7 MHz 90.6 MHz
II13 90.8 - 91.0 MHz 90.9 MHz
II14 91.1 - 91.3 MHz 91.2 MHz
II15 91.4 - 91.6 MHz 91.5 MHz
II16 91.7 - 91.9 MHz 91.8 MHz
II17 92.0 - 92.2 MHz 92.1 MHz
II18 92.3 - 92.5 MHz 92.4 MHz
II19 92.6 - 92.8 MHz 92.7 MHz
II20 92.9 - 93.1 MHz 93.0 MHz
II21 93.2 - 93.4 MHz 93.3 MHz
II22 93.5 - 93.7 MHz 93.6 MHz
II23 93.8 - 94.0 MHz 93.9 MHz
II24 94.1 - 94.3 MHz 94.2 MHz
II25 94.4 - 94.6 MHz 94.5 MHz
II26 94.7 - 94.9 MHz 94.8 MHz
II27 95.0 - 95.2 MHz 95.1 MHz
II28 95.3 - 95.5 MHz 95.4 MHz
II29 95.6 - 95.8 MHz 95.7 MHz
II30 95.9 - 96.1 MHz 96.0 MHz
II31 96.2 - 96.4 MHz 96.3 MHz
II32 96.5 - 96.7 MHz 96.6 MHz
II33 96.8 - 97.0 MHz 96.9 MHz
II34 97.1 - 97.3 MHz 97.2 MHz
II35 97.4 - 97.6 MHz 97.5 MHz
II36 97.7 - 97.9 MHz 97.8 MHz
II37 98.0 - 98.2 MHz 98.1 MHz
II38 98.3 - 98.5 MHz 98.4 MHz
II39 98.6 - 98.8 MHz 98.7 MHz
II40 98.9 - 99.1 MHz 99.0 MHz
II41 99.2 - 99.4 MHz 99.3 MHz
II42 99.5 - 99.7 MHz 99.6 MHz
II43 99.8 - 100.0 MHz 99.9 MHz
II44100.1 - 100.3 MHz100.2 MHz
II45100.4 - 100.6 MHz100.5 MHz
II46100.7 - 100.9 MHz100.8 MHz
II47101.0 - 101.2 MHz101.1 MHz
II48101.3 - 101.5 MHz101.4 MHz
II49101.6 - 101.8 MHz101.7 MHz
II50101.9 - 102.1 MHz102.0 MHz
II51102.2 - 102.4 MHz102.3 MHz
II52102.5 - 102.7 MHz102.6 MHz
II53102.8 - 103.0 MHz102.9 MHz
II54103.1 - 103.3 MHz103.2 MHz
II55103.4 - 103.6 MHz103.5 MHz
II56103.7 - 103.9 MHz103.8 MHz
II57104.0 - 104.2 MHz104.1 MHz
II58104.3 - 104.5 MHz104.4 MHz
II59104.6 - 104.8 MHz104.7 MHz
II60104.9 - 105.1 MHz105.0 MHz
II61105.2 - 105.4 MHz105.3 MHz
II62105.5 - 105.7 MHz105.6 MHz
II63105.8 - 106.0 MHz105.9 MHz
II64106.1 - 106.3 MHz106.2 MHz
II65106.4 - 106.6 MHz106.5 MHz
II66106.7 - 106.9 MHz106.8 MHz
II67107.0 - 107.2 MHz107.1 MHz
II68107.3 - 107.5 MHz107.4 MHz
II69107.6 - 107.8 MHz107.7 MHz


















Spectrummonitoring.com uses cookies to improve your experience while you browse through our webpages. These cookies are stored on your device and are essential for the working of the basic functionalities of our website. Spectrummonitoring.com doesn't use any third-party cookies.
